High voltage suspension 100 kN toughened glass insulator U100BP glass insulators

100kN standard disc suspension glass insulator U100BP Jiangxi Huayao High Voltage Disc electric isolators glass suspension insulator Toughened Glass Insulator U100BP Glass insulator is a special insulation component used in overhead transmission lines to provide insulation and support for wires.

Structural composition:

Glass insulators are usually composed of iron caps, tempered glass pieces, and steel feet, which are bonded together with cement adhesive.

Main types of glass insulator:

Glass insulator is including standard type, pollution resistant type, DC type, spherical type, aerodynamic type, ground wire type, and contact network for electrified railways Jiangxi Huayao electric Co.,ltd produce standard type glass insulator 40-550Kn, Pollution resistant type 70-400Kn, mutil-umbrella type 120-330kN, Glass insulator aerodynamic type 120-300kN, ground wire type.

Main types of glass insulator：

Following is anti fog type glass insulator 40-550Kn:

Product Details

100kN standard disc suspension glass insulator U100BP Place of Origin:  China Brand name:  HUAYAO Certification:  ISO9001 Daily output:  10000 pieces 6 pieces in wooden case, then put in pallet. Payment & Shipping Minimum Order Quantity: 10 pieces Packaging Details:  normal export packaging Supply Ability:  50000pcs Delivery Port:  Ningbo,Shanghai Payment term:  TT, L/C, FCA

Quick Detail：

Glass Standard Profile Suspension Insulators LXP2-100 / U100BL Dimensions Diameter (D): 320mm Spacing (H): 146mm Creepage Distance: 320mm Coupling Size: 16mm Mechanical Values Mechanical Failing Load: 100kN Tension Proof: 50kN Electrical Values Dry Power-frequency Withstand Voltage: 70kV Wet Power-frequency Withstand Voltage: 40kV Dry Lightning Impulse Withstand Voltage: 100kV Puncture Withstand Voltage: 130kV Radio Influence Voltage Data Test Voltage RMS to Ground: 10kV Maximum RIV at 1000 kHz: 50μV Packing and Shipping Data Net Weight, Approximate: 7.5kg

Test report of Jiangxi huayao electric Co.,ltd glass insulator:

Jiangxi Huayao electric Co.,ltd provide test report from third party such as Xi'an High Voltage Apparatus Research Institute Co., Ltd. (XIHARI) ,National ceramic product quality inspection and test center.
Pre-shipment inspection from third party such as INTERTEK, SGS, BV or customer themselves.

The Production process flow:

Standard of glass insulator:

The tests have been performed in accordance with:
GB/T1001.1-2021 Insulators for overhead lines with a norminal voltage above 1000V Part1: Ceramic or glass insulator units for a.c. systems Definitions, test methods and acceptance criteria (IEC 60383-1:2021 MOD)
GB/7253-2019 Insulator for overhead lines with a nominal voltage above 1000V-Ceramic or glass insulator units for a.c. systems-Characteristics of insulator units of cap and pin type (IEC 60305:2021 MOD)
IEC 60383-1:2023 Insulators for overhead lines with a norminal voltage above 1000V
IEC 60120:2020 Dimensions of ball and socket couplings of string insulator units
Jiangxi Huayao electric Co.,ltd strictly compliance with above standard. We do the factory test report as above standard.
We always do following test for each products:
1. Verification of the Dimensions
2. Verifications of Displacements
3. Locking system test
4. Galvanized test
5. Thermal shock test
6. Mechanical Failing Load Test
7.Power frequency puncture withstand test

Package of the glass insulator：
